SFP-SX-D
1000Base-SX GBIC Transceiver
Multimode Transceiver, up to 220 m reach (62.5um)/ 550 m reach (50 um), LC connector
Gigabit Speed and Flexibility
ZyXEL's Gigabit Interface Converter (GBIC) transceiver family provides performance and flexibility with full duplex Gigabit speeds and hot-pluggable into Gigabit Ethernet port.
Industry Standards-based Compliance
ZyXEL's GBIC transceiver family is compliant with IEEE 802.3z and GBIC Revision 5.5 allowing easy interoperability with all standard compliance devices from different vendors. For multi-mode / single-mode fiber optic, ZyXEL GBIC transceivers provide high transmission performance and quality for different distances requirement from 220m to 80Km.
Specification
- Gigabit Speed and Flexibility
- Compact Size
- Flexible Implementation
- Hot Pluggable
- Dual Power Supply +5V and +3.3 V
- GBIC Revision 5.5 Compliant
- 1.25Gbps Gigabit Ethernet Compliant
- Class 1 Laser Safety Standard IEC 825 Compliant
Dimension
Optical Receiver Sensitivity
Wavelength
Connector
Transmission Distance vs. Fiber Cable Specification
- 62.5um MMF: 220 m
- 50um MMF: 550 m
Operational Ranges
- Supply Voltage: 3.15~5.25 V
- Max Current: 300mA
Safety Certification
- Class 1 Laser
- 21 CFR 1040.10 and 1040.11 Compliant
- CSA
- TUV
Operating Environment Information
- Operating Temperature: 0°C ~ 70°C
- Storage Temperature: -40°C ~ 85°C
- Relative Humidity: 5% - 95%
| Maximum data transfer rate | 1000 Mbit/s |
| Maximum transfer distance | 550 m |
| Wavelength | 850 nm |
| Cabling technology | 1000Base-LHX |
| Form factor | Plug-in |
| Safety | Class 1 Laser, CSA, TUV, 21 CFR 1040.10 & 1040.11 |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Width | 56 mm |
| Depth | 13.4 mm |
| Height | 12.5 mm |
| Harmonized System (HS) code | 85369010 |
| Dimensions (WxDxH) | 56 x 13.4 x 12.46 mm |
