Connectivity technology | Wired |
Host interface | USB 3.2 Gen 2 (3.1 Gen 2) Type-C |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
HDMI ports quantity | 1 |
VGA (D-Sub) ports quantity | 1 |
Microphone in | No |
Ethernet LAN | Yes |
Ethernet LAN (RJ-45) ports | 1 |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Full duplex | Yes |
Product colour | Black, Silver |
Data transfer rate | 10 Gbit/s |
Maximum digital resolution | 3840 x 2160 pixels |
Maximum analog resolution | 2048 x 2180 pixels |
Maximum refresh rate | 30 Hz |
UASP support | Yes |
Housing material | Aluminium, Plastic |
Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64 |
Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura |
Mobile operating systems supported | Android |
Other operating systems supported | ChromeOS |
Operating temperature (T-T) | 0 - 60 °C |
Storage temperature (T-T) | -20 - 60 °C |
Operating relative humidity (H-H) | 0 - 90% |
Sustainability compliance | Yes |
Width | 61 mm |
Depth | 360 mm |
Height | 15 mm |
Weight | 54 g |
Quantity per pack | 1 pc(s) |
Package width | 210 mm |
Package depth | 142 mm |
Package height | 38 mm |
Package weight | 164 g |
Quick start guide | Yes |
Compliance certificates | CE, RoHS |
Products per master (outer) case | 20 pc(s) |
Master (outer) case width | 415 mm |
Master (outer) case length | 235 mm |
Master (outer) case height | 318 mm |
Harmonized System (HS) code | 84733020 |
Cable length | 0.25 m |
Chipset | Genesys Logic - GL3590, ITE Tech - IT6564FN, Silicon Labs - EFM8UB20F32G |
