Connectivity technology | Wired |
Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
USB Power Delivery | Yes |
USB Power Delivery revision | 3.0 |
USB Power Delivery up to | 100 W |
HDMI ports quantity | 1 |
VGA (D-Sub) ports quantity | 1 |
Combo headphone/mic port | Yes |
Headphone outputs | 1 |
Ethernet LAN | Yes |
Ethernet LAN (RJ-45) ports | 1 |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Product colour | Black, Grey |
Card reader integrated | Yes |
Compatible memory cards | SD, SDHC, SDXC |
Data transfer rate | 5 Gbit/s |
Maximum digital resolution | 4096 x 2160 pixels |
Maximum analog resolution | 1920 x 1200 pixels |
Housing material | Aluminium, Plastic |
Certification | CE, FCC, REACH |
Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64 |
Mac operating systems supported | Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura |
Mobile operating systems supported | Android, iOS |
Other operating systems supported | ChromeOS |
Operating temperature (T-T) | 0 - 45 °C |
Storage temperature (T-T) | -10 - 82 °C |
Operating relative humidity (H-H) | 5 - 90% |
Width | 61 mm |
Depth | 460 mm |
Height | 15 mm |
Weight | 125 g |
Package width | 145 mm |
Package depth | 117 mm |
Package height | 30 mm |
Package weight | 190 g |
Quick start guide | Yes |
Compliance certificates | RoHS |
Products per master (outer) case | 70 pc(s) |
Master (outer) case width | 335 mm |
Master (outer) case length | 470 mm |
Master (outer) case height | 440 mm |
Harmonized System (HS) code | 84733020 |
Cable length | 0.3 m |
Chipset | VIA Labs - VL102, VIA Labs - VL161, VIA Labs - VL817, Genesys Logic - GL823K, ITE Tech - IT6564, Realtek - RTL8153B, Cmedia - HS100-B |
