Performance |
---|
USB version | 3.2 Gen 1 (3.1 Gen 1) |
USB connector type | USB Type-A |
USB connector gender | Male |
DVI output | No |
HDMI output | No |
DisplayPort output | Yes |
Number of displays supported | 1 |
Internal memory | 64 MB |
Maximum resolution | 3840 x 2160 pixels |
Refresh rate at maximum resolution | 30 Hz |
Supported graphics resolutions | 640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768, 1280 x 800, 1366 x 768, 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2048 x 1152, 3840 x 2160 |
Audio output channels | 2.0 channels |
Chipset | Trigger - T6-688L |
USB pass-through | No |
Certification | Microsoft WHQL, CE, FCC, REACH |
Design |
---|
Product colour | Black |
Housing material | Plastic |
System requirements |
---|
Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
Minimum processor family | Core i5 |
Minimum processor speed | 2.4 GHz |
Minimum RAM | 4 GB |
Weight & dimensions |
---|
Width | 55 mm |
Depth | 75 mm |
Height | 16 mm |
Weight | 58 g |
USB cable length | 0.2 m |
Operational conditions |
---|
Operating temperature (T-T) | 0 - 45 °C |
Storage temperature (T-T) | -15 - 75 °C |
Operating relative humidity (H-H) | 0 - 85% |
Packaging data |
---|
Package width | 144 mm |
Package depth | 210 mm |
Package height | 38 mm |
Package weight | 190 g |
Packaging content |
---|
Quick installation guide | Yes |
Technical details |
---|
Compliance certificates | RoHS |
Logistics data |
---|
Products per master (outer) case | 40 pc(s) |
Master (outer) case width | 315 mm |
Master (outer) case length | 440 mm |
Master (outer) case height | 430 mm |
Harmonized System (HS) code | 84733020 |
