STARTECH StarTech.com 4 Bay USB 3.0/ eSATA Hard Drive Duplicator Dock for 2.5" & 3.5" SATA/ IDE SSD HDD - Standalone 1:3 Copier Docking Station (SATDOCK4U3RE) - Hard drive duplicator - 4 bays (SATA-300) - for
You have to log in to shop/see prices.
|
STARTECH StarTech.com 4 Bay USB 3.0/ eSATA Hard Drive Duplicator Dock for 2.5" & 3.5" SATA/ IDE SSD HDD - Standalone 1:3 Copier Docking Station (SATDOCK4U3RE) - Hard drive duplicator - 4 bays (SATA-300) - for
Product number:
SATDOCK4U3RE
-
Disk Interface
eSATA, USB
-
Installed
0GB
-
Max Disks
4
-
RAID
No
-
Type
External
-
Disk Size
3.5"
|
Description
Specifications
Quad Bay Hard Drive Duplicator & Eraser 2.5/3.5" HDD/SSD Disk Cloner
The SATDOCK4U3RE USB 3.0 and eSATA 1-to-3 Hard Drive Duplicator docking station enables you to duplicate/clone a single SATA hard drive to up to three other SATA drives simultaneously, as a standalone device. The duplicator can also function as a regular 4-bay hard drive docking station, by connecting to a host computer system. Large capacity drives (tested with up to 4TB 3.5" and 1TB 2.5" drives per bay) can be used to greatly enhance your computer's storage/backup capabilities.
Able to perform 1:3 sector duplication, including HPA, from a single SATA drive onto three others simultaneously (at a rate of up to 72 MBps), the duplicator/docking station can save you time and effort. As an external HDD dock, it can be connected to your host computer through USB 3.0 or eSATA, providing data transfer speeds up to 5 Gbps or 3Gbps respectively, from the hard drives to your computer system.
Features Quick and Secure Erase functions and support for IDE hard drives using the included SATA to IDE hard drive adapter (SAT2IDEADP). This drive eraser ensures data is purged (a secure erase) which is required by government agencies and organizations who have strict guidelines on deleting data. Purging is a very secure method of erasing data from your storage device which complies with the NIST 800-88 Rev. 1 media sanitation standard established by the National Institute of Standards and Technology.
The StarTech.com Advantage
Product type | HDD duplicator |
Number of simultaneous copies | 3 copies |
Interface | USB/eSATA |
USB connector type | USB Type-B |
Duplicator operating modes | Copy |
Product colour | Black |
Housing material | Plastic |
Maximum supported storage capacity | 16 TB |
Plug and Play | Yes |
Display | LCD |
Chipset | JMicron - JMB394 + JMS539 |
Number of fans | 2 fan(s) |
Fan diameter | 6 cm |
Port multiplier | Yes |
LED indicators | Activity, Power |
Compliance certificates | RoHS |
Certification | CE |
Supported HDD sizes | 2.5,3.5" |
Supported HDD interfaces | Serial ATA, Serial ATA II |
Compatible operating systems | Windows 2000/ XP(32/64-bit)/ Server 2003(32/64-bit)/ Vista(32/64-bit)/ 7(32/64-bit)/ Server 2008 R2, Mac OS X, Linux |
Power consumption (typical) | 78 W |
AC input voltage | 110-240 V |
Output voltage | 12 V |
Output current | 6.5 A |
Included power plug types | EU, NA, UK |
Dimensions (WxDxH) | 285 x 170 x 94 mm |
Weight | 1.1 kg |
Package width | 170 mm |
Package depth | 343 mm |
Package height | 215 mm |
Package weight | 2.73 kg |
Cables included | SATA, USB, eSATA |
AC adapter included | Yes |
Manual | Yes |
Operating relative humidity (H-H) | 8 - 90% |
Operating temperature (T-T) | 5 - 80 °C |
Storage temperature (T-T) | -40 - 70 °C |
Master (outer) case length | 368 mm |
Master (outer) case width | 364 mm |
Master (outer) case height | 475 mm |
Products per master (outer) case | 4 pc(s) |
