STARTECH 10 Gigabit Fiber SFP+ - HP J9150A Compatible - MM 300m/984'
Frontpage
STARTECH 10 Gigabit Fiber SFP+ - HP J9150A Compatible - MM 300m/984'
You have to log in to shop/see prices.
|
STARTECH 10 Gigabit Fiber SFP+ - HP J9150A Compatible - MM 300m/984'
Product number:
J9150A-ST
-
Product
Transceiver / GBIC / SFP
|
Description
Specifications
10 Gbps | Multi Mode Fiber | LC | 300 m (984 ft) | Lifetime WarrantyThe J9150AST is an HPE J9150A compatible fiber transceiver module that has been designed, programmed and tested to work with HPE® brand switches and routers. It delivers dependable 10 GbE connectivity over fiber cable, for 10GBASE-SR compliant networks, with a maximum distance of up to 300 m (984 ft).Technical Specifications:• Wavelength: 850 nm• Maximum Data Transfer Rate: 11.1 Gbps• Type: Multi Mode Fiber• Connection Type: LC Connector• Maximum Transfer Distance: 300 m (984 ft)• MTBF: 1,967,709 hours• Power Consumption: Less than 1.2 Watts• Digital Diagnostics Monitoring (DDM): YesThis SFP+ fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.StarTech.com SFPsAll StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.The StarTech.com Advantage
SFP transceiver type | Fiber optic |
Maximum data transfer rate | 11100 Mbit/s |
Interface type | SFP+ |
Multi-mode fiber (MMF) supported | Yes |
Fiber optic connector | LC |
SFP transceiver standard | SR |
Maximum transfer distance | 300 m |
Wavelength | 850 nm |
Networking standards | IEEE 802.3ae |
Duplex system | Full |
Digital Diagnostics Monitoring (DDM) | Yes |
Wavelength-division multiplexing (WDM) | No |
Product colour | Silver |
Hot-swap | Yes |
Mean time between failures (MTBF) | 1967709 h |
Power consumption (typical) | 1.2 W |
Compliance certificates | RoHS |
Certification | CE, FCC, UL |
Operating temperature (T-T) | 0 - 70 °C |
Storage temperature (T-T) | -40 - 85 °C |
Operating relative humidity (H-H) | 30 - 75% |
Width | 14 mm |
Depth | 57 mm |
Height | 13 mm |
Weight | 20 g |
Quantity per pack | 1 pc(s) |
Package width | 94 mm |
Package depth | 117 mm |
Package height | 33 mm |
Package weight | 95 g |
Master (outer) case width | 261 mm |
Master (outer) case length | 302 mm |
Harmonized System (HS) code | 85369010 |
Master (outer) case height | 201 mm |
Products per master (outer) case | 36 pc(s) |
