Ports & interfaces |
---|
Connectivity technology | Wired |
Host interface | PCI Express |
Interface | Fiber |
Fiber ports quantity | 2 |
Fiber optic connector | SFP28 |
PCI version | 4.0 |
Network |
---|
Networking standards | IEEE 1588, IEEE 1588v2, IEEE 802.1p |
Ethernet interface type | 10 Gigabit Ethernet, 25 Gigabit Ethernet, Gigabit Ethernet |
Ethernet LAN data rates | 1000,10000,25000 Mbit/s |
Quality of Service (QoS) support | Yes |
LAN controller | Intel E810 |
Design |
---|
Internal | Yes |
Component for | Server |
Product colour | Black, Green, Silver |
LED indicators | Activity, Link |
Certification | FCC B, UL, CE, VCCI, BSMI, RCM, KCC |
System requirements |
---|
Compatible operating systems | https://www.intel.com/content/www/us/en/support/articles/000025890/ethernet-products.html |
Operational conditions |
---|
Operating temperature (T-T) | 0 - 55 °C |
Storage temperature (T-T) | -40 - 70 °C |
Weight & dimensions |
---|
Width | 167 mm |
Depth | 68 mm |
Logistics data |
---|
Harmonized System (HS) code | 85176990 |
Other features |
---|
Cable type | SFP28 ports - DAC, Optics, and AOC's |
Intel Virtual Machine Device Queues (VMDq) | Yes |
PCI-SIG* SR-IOV Capable | Yes |
On-chip QoS and Traffic Management | Yes |
Intel Flexible Port Partitioning | Yes |
Speed & slot width | 16.0 GT/s, x8 Lane |
Intelligent Offloads | Yes |
iWARP/RDMA | Yes |
Intel Data Direct I/O Technology | Yes |
Intel Virtualization Technology for Connectivity (VT-c) | Yes |
Processor family | 800 Network Adapters (up to 100GbE)-800 Network Adapters (up to 100GbE) |
Ethernet adapter ARK ID | 189760 |
Export Control Classification Number (ECCN) | 5A991 |
Commodity Classification Automated Tracking System (CCATS) | NA |
Bracket height | Low-Profile (LP) / Full-Height (FH) |
Storage Over Ethernet | iSCSI, NFS |
Launch date | Q3'20 |
Network interface card cable medium | Copper, Fiber |
Network interface card type | Server |
Status | Launched |
Product series | 800 Series Network Adapters (up to 100GbE) |
