Processor manufacturer | AMD |
Processor socket | Socket AM4 |
Compatible processor series | AMD Athlon, AMD Ryzen™ 3, AMD Ryzen™ 5, AMD Ryzen™ 7, 3rd Generation AMD Ryzen™ 9 |
Maximum number of SMP processors | 1 |
Supported memory types | DDR4-SDRAM |
Number of memory slots | 4 |
Memory slots type | DIMM |
Memory channels | Dual-channel |
ECC | Yes |
Supported memory clock speeds | 2133,2400,2666,2800,3000,3200,3333,3466,3600,3733,3866,4000,4133,4266,4400,4466,4600,4800 MHz |
Maximum internal memory | 128 GB |
Unbuffered memory | Yes |
Supported storage drive types | HDD & SSD |
Supported storage drive interfaces | SATA III |
RAID levels | 0, 1, 10 |
Parallel processing technology support | Not supported |
USB 2.0 connectors | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
Number of SATA III connectors | 4 |
Front panel audio connector | Yes |
ATX Power connector (24-pin) | Yes |
Number of EATX power connectors | 1 |
CPU fan connector | Yes |
Number of chassis fan connectors | 2 |
Chassis intrusion connector | Yes |
Number of COM connectors | 1 |
Thunderbolt headers | 1 |
12V power connector | Yes |
USB 2.0 ports quantity | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
PS/2 ports quantity | 2 |
HDMI ports quantity | 1 |
HDMI version | 2.1 |
DisplayPorts quantity | 2 |
Ethernet LAN | Yes |
Ethernet interface type | Gigabit Ethernet |
LAN controller | Realtek RTL8111H |
Wake-on-LAN ready | Yes |
Component for | PC |
Motherboard form factor | micro ATX |
Motherboard chipset family | AMD |
Motherboard chipset | AMD B550 |
Audio chip | Realtek ALC887 / Realtek ALC897 |
Audio output channels | 7.1 channels |
Windows operating systems supported | Windows 10 x64 |
PCI Express x4 slots | 1 |
PCI Express x16 (Gen 4.x) slots | 1 |
PCI slots | 1 |
Number of M.2 (M) slots | 2 |
BIOS type | UEFI AMI |
BIOS memory size | 256 Mbit |
Clear CMOS jumper | Yes |
Harmonized System (HS) code | 84733020 |
Width | 244 mm |
Depth | 244 mm |
Height | 51 mm |
Cables included | SATA |
Drivers included | Yes |
Weight | 845 g |
