Allied Telesis s Industrial Ethernet Media Converter AT-IMC200TP/SC - Fibre media converter - 100Mb LAN - 10Base-T, 100Base-FX, 100Base-TX - RJ-45 / SC multi-mode - up to 2 km - 1310 nm

Frontpage Allied Telesis s Industrial Ethernet Media Converter AT-IMC200TP/SC - Fibre media converter - 100Mb LAN - 10Base-T, 100Base-FX, 100Base-TX - RJ-45 / SC multi-mode - up to 2 km - 1310 nm
You have to log in to shop/see prices.
Allied Telesis s Industrial Ethernet Media Converter AT-IMC200TP/ SC - Fibre media converter - 100Mb LAN - 10Base-T, 100Base-FX,  100Base-TX - RJ-45 / SC multi-mode - up to 2 km - 1310 nm (AT-IMC200TP/SC-980)

Allied Telesis s Industrial Ethernet Media Converter AT-IMC200TP/SC - Fibre media converter - 100Mb LAN - 10Base-T, 100Base-FX, 100Base-TX - RJ-45 / SC multi-mode - up to 2 km - 1310 nm

Product number:
AT-IMC200TP/SC-980
EAN:
767035210537
  • Product Media converter
Out of stock
Description

10/100/1000T to 100FX/SC Industrial temperature PoE+ media converter. These converters support 802.3at, PoE+, 30W, LTPoE++ and 4-pair up to 70W. The IMC200TP/SC-980 features Remote Power Cycle and Smart MissingLink™ (SML) and is fanless for silent operation.

Powering remote devices
Allied Telesis IMC200/2000 Series Industrial Media Converters (IMCs) are ideal for powering remote devices, such as IP phones, video cameras and wireless Access Points (APs), which are more than 100m from a Power over Ethernet (PoE) switch. Each IMC can provide up to 70W of PoE.

The 2000T/SP and the 2000TP/SP each feature a 10/100/1000T twisted-pair port, and an SFP port which supports and auto detects 100X and 1000X optics. No switch configuration is needed. Allied Telesis offers a wide variety of SFPs featuring multimode, single mode and BiDi optics.

Models with a fixed fiber-optic port are available with SC or LC connectors. With these, you can achieve distances up to 2 km (100Mps) or 550 m (1000Mps). With the SFP model, you can achieve greater distances using a long-range SFP.

In addition to transmitting data, the twisted-pair port also injects power down the cable, allowing a remote PoE powered device to operate without any additional power source. All PoE+ devices (IEEE802.3at compliant) are supported. All PoE+ devices support 802.3at, PoE+, LTPoE++ and 4-pair. The PC200x PoE+ Series can deliver up to 70W of power to the remote device.

Remote Power Cycle
The IMC200/2000 Series supports the Remote Power Cycle feature. This allows a remote administrator to log in to the host switch device and disable the switch port to which the IMC is attached, causing the PoE+ device to lose power. This allows administrators to reset remote devices without physically going to the location.

Jumbo frame support
Many backbone switch products support the industry-standard IEEE 802.1Q specification for Virtual LANs (VLANs) which sends extra-long data packets on the network. The IMC200/2000 Series are fully compatible with these long packets, enabling them to be used in modern networks.

Smart MissingLink™ (SML)
The SML feature monitors network connections and provides a notification when a link fails, allowing administrators to quickly identify the source and location of failed links, and thus minimize downtime.
